Controller DC Power Supply

Kaihong is a professional China Controller DC Power Supply manufacturers and suppliers. Controller DC power supply, with small size, light weight, high power, high precision. Can adapt to resistive, inductive, capacitive and other loads.

Send Inquiry

Product Description

Kaihong is Controller DC Power Supply manufacturers and suppliers in China who can wholesale Controller DC Power Supply. Controller DC power supply, with small size, light weight, high power, high precision. Can adapt to resistive, inductive, capacitive and other loads. The power supply of high power controller adopts the current wide range of high frequency modulation technology, which broadens the voltage and current of DC power supply of controller, realizes the wide range of voltage and current regulation, and expands the application field of DC power supply. The control chip of high power DC power supply adopts mature imported components, which solves the problem of low reliability due to multi-tube parallel connection, and makes the power supply process of high power controller more reasonable. Controller power is widely used in electric vehicle assembly line, controller production line, electric vehicle controller research and development, controller debugging test aging, vehicle delivery test.


Controller DC power supply technical specifications:

1. Continuous adjustable range of constant pressure value: 0 -- rated value

2. Continuous adjustable range of constant current value: 0 -- rated value

3. Voltage protection value feature: automatically track the output voltage

4. Load effect (current adjustment rate) : constant voltage (CV) is less than 0.1%

5. Source effect (voltage adjustment rate) : constant voltage (CV) is less than 0.1%+50MV

6. Ripple coefficient: constant voltage (CV) less than 0.2%(effective value)

7. Protection function: short circuit, over voltage, over current, overheating, lack of phase

8. Insulation resistance: ≥05MΩ

9. Compressive strength: 1500V 60S

10. Temperature coefficient: less than 0.4×10-4℃(after preheating for 30 minutes)

11. Input power supply: ~380V±10%/, 50HZ


Controller DC Power Supply specifications:

Current (A) : 1A-3000A (optional)

Voltage (V) : 5V-1500V (optional)
